MKS Instruments UK Ltd
Microvision2 Hardware Manual – SP101015.102 August 2010
8
1.6 Warning labels
Refer to:
a. Accessible hazardous voltages on analyser connector, when not mated to the analyser, which may result
in a non-hazardous electric stock if touched.
b. Tuning adjustment holes, which are not for operator use.
On the rear panel refers to:
a. Read all instructions carefully before use.
b. The control unit and signal ports are designed for connection to MKS accessories via MKS supplied
cables.
There are no accessible hazardous voltages or currents on these ports.
MKS must be consulted before any non-MKS supplied cables or accessories are connected to these ports.
1.7 Ventilation
The openings in the sides and rear panels must not be obstructed.
Allow a minimum clearance of 50mm all round.
Do not exceed the maximum operating ambient temperature.
