Chapter Two: Installation
32
2 Tube #2 Signal White Tube#2, Pin 3/Signal Output
3 Tube #2 Signal Return Brown Tube#2, Pin 4/Signal Common
4 +15 volts Red Tube#1, Pin 1/+15 VDC
5 +15 volts Red Tube#2,Pin 1/+15 VDC
6 -15 volts Green Tube#1, Pin 2/-15 VDC
7 -15 volts Green Tube#2, Pin 2/-15 VDC
8 Tube #1 Signal Return Brown Tube#1, Pin 4/Output Return
9 Electronics Common
Black/shield
Black/shield
Tube#1, Pins5/Pwr.Comm & none
Tube#2,Pins5/Pwr.Comm & none
Table 3: PDR 2000 9-Pin ‘D’ - MKS Baratron 5-Pin Phoenix Connections
Current available for +15 volts from pins 4 and 5 and for –15 volts from pins 6 and 7 is internally
protected and limited to approximately 0.75 amp total for each supply. For example, this allows CDG#1
and CDG#2 to draw 0.375 amp each; or CDG#1 may draw 0.72 amp and CDG#2 may draw 0.03 amp. If
excessive current is taken through any of the power outut pins, the internal protection will shut off the
power for the affected voltage. It will be necessary to disconnect power for thePDR 2000 for a few
minutes to allow the internal protection device to cool and reset itself.
