Full Scale Of the Gauges
To read the full scale range selected during set up for each gauge:
Send “f” (ASCII value 102); the PDR 2000 returns full scale, which the user has selected for each gauge
in the format:
JKLMeN OPQReS
Where:
• JKLM is the multiplier and N is the exponent for CDG #1.
• OPQR is the multiplier and S is the exponent for CDG #2.
• Some examples follow on the next page in Table 8.
Serial Output and Full Scale Range Setting
Full Scale Serial Serial Output
50 mTorr 50.00e-3
100 mTorr 100.0e-3
1 Torr 1.000e+0
100 Torr 100.0e+0
1000 Torr 1000e+0
10000 Torr 10.000e+3
Table 8: Serial Output and Full Scale Range Setting
Units of Measurement
To read the chosen units of measure (both gauges):
Send “u” (ASCII value 117); the PDR 2000 returns:
Torr
