MKS PDR 2000 - Page 9

4
List of Figures and Tables
Figures
Figure 1: Model PDR 2000 Front View.........................................................................................22
Figure 2: Model PDR 2000 Rear View..........................................................................................23
Figure 3: Model PDR 2000 Dimensions........................................................................................23
Figure 4: Model PDR 2000 Sensor Connector – 9 Pin Female D-Sub Connector ........................28
Figure 5: RS-232 I/O; Analog Out; Relays....................................................................................30
Tables
Table 1: Definition of Symbols Found on the Unit .........................................................................1
Table 2: PDR 2000 9-Pin ‘D’ - MKS Baratron 15-Pin ‘D’ Connections .....................................28
Table 3: PDR 2000 9-Pin ‘D’ - MKS Baratron 5-Pin Molex Connections ..................................29
Table 4: PDR 2000 15 Pin - Accessory Connector Signals and Pins ...........................................30
Table 5: PDR 2000 Ranges: Sensor, High, Low, Set Points.........................................................37
Table 6: Analog Output and Displayed Pressure..........................................................................38
Table 7: Serial Output and Displayed Pressure ............................................................................39
Table 8: Serial Output and Full Scale Range Setting ...................................................................40
Table 9: Information on Replacing Fuses.....................................................................................42
