Camera Housing and Connectors– D15
The MOBOTIX D15D consists of three main components (camera housing, outer shell and
dome).
4 2
3
1
4 LEDs (behind PIR
cover)
Speaker
Dome
PIR sensor
Lens unit I
Lens unit II
Sensor cable
MicroSD card
MxBus
MxBus cabling
MiniUSB
Ethernet
Washer
Water outlet open-
ings
Outer shell
Microphone
Two freely positionable lens units
Ø 205mm/8.07in
108mm/4.25in
LED default settings:
1 Power (on), error (ashes)
2 Recording (ashes)
3 Off
4 Off
