D15 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
1.3 Delivered Parts
1.3.1 Standard Delivery – D15
Item Number Part Name
1.1 1 Camera housing
1.2 2 Lens (installed)
1.3 2 Lens mount
1.4 – (Removed)
1.5 2 Sensor cable (installed, not shown)
1.6 1 Cable cover (installed)
1.7 2 Dome (1x transparent– installed, 1x tinted)
1.8 1 Outer shell
1.9 1 Ethernet cable (installed)
1.10 1 Allen wrench 3mm
1.11 1 TX20 Torx wrench
1.12 1 Custom tool with magnet
1.13 1 MxBus connector (installed, not shown):
1.14 1 MicroSD card (SDXC, SDHC pre-installed)
Installation accessories
Item Number Part Name
M.1.1 3 Screw anchors 8mm
M.1.2 3 Stainless steel washers, diam. 5.3mm
M.1.3 3 Stainless steel wood 4.5 x 60mm screws with TX20
head
2 lenses (item 1.2)
2 lens mounts (item 1.3)
Custom tool
with magnet (item 1.12)
Outer shell (item 1.8)
3 mm Allen wrench (item 1.10)
TX20 Torx wrench (item 1.11)
Camera housing (item 1.1)
Domes (item 1.7),
1x transparent, 1x tinted
Cable cover (item 1.6)
Ethernet cable (item 1.9)
