2.4.2 Mounting the Outdoor Wall Mount
Ideally, the Outdoor Wall Mount is mounted over the tested wall outlet that provides the
connections (network, Power-over-Ethernet) to the camera.
MX-Overvoltage-Protection-Box or wall outlet
D15 Outdoor Wall Mount
MOBOTIX Ethernet patch cable (1 m)
D15
In-wall socket
Mounting the Outdoor
Wall Mount over the
MX-Overvoltage-Protection-Box
or a socket
293
90
9037
75
160
MOBOTIX interface
boxes (here: the
MX-Overvoltage-Protection-Box)
also t in the 90
x 90 mm space
