Preparing The Installation
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Non-Square Rooms
When viewing a 360° (full) image in the browser, you will notice that the top and bottom
of the image is not fully visible, i.e. some image information has been clipped. This is not
a fault of the camera, but intended behavior that aims at achieving the best possible
utilization of the image sensor by the camera software. Bearing this in mind, it is advisable
to install the Q24M in rectangular room ceilings so that the arrow marked OBEN/ TOP
points towards one of the longer walls of the room as shown in the figure.
Original full image
from the Q24M (ceil-
ing installation in a
rectangular room)
