Mobotix Q24M - Q24 M Basic;Secure: Delivered Parts, Components, Dimensions; Delivered Parts and Camera Components

54/164
Q24M Camera Manual: Installation
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
2.2 Q24M Basic/Secure: Delivered Parts, Components, Dimensions
2.2.1 Delivered Parts And Camera Components
Item Quantity Part Name
1.1 1 Camera
1.2 1 Lens
1.3 1 Lens wrench
1.4 1 MicroSD card (4 GB)*, pre-installed
1.5 1 CAT5 patch cable, 0.5m incl. washer, pre-installed
1.6 1 Allen wrench 3mm
1.7 1 Allen wrench 2mm
1.8 1 Torx wrench
1.9 1 Outer shell
1.10 1 Mounting ring
1.11 4 Universal screw anchors 8 mm
1.12 4 Stainless steel washers Ø 5,3mm
1.13 4 Stainless steel wood screws with hex head 4.5x60mm
1.14 4 Stainless steel Allen screws M4x16 mm
1.15 4 Stainless steel washers Ø 4.3mm
1.16 2 Cable retainer with bayonet catch (patch cable, MiniUSB)
*MicroSD card only avail-
able for Q24M Secure
