Mobotix Q24M - Corner and Pole Mount

95/164
Installing The Corner And Pole Mount
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
2.9.2 Corner And Pole Mount
Item Quantity Part Name
6.1 1 Pole mount, stainless steel, white, powder-coated
6.2 4 Stainless steel Allen screws M6x20mm
6.3 4 Stainless steel washers Ø 6mm
6.4 4 Stainless steel lock nuts M6
6.5 2 Stainless steel straps
6.6 2 Cable fitting with counter nut and O-ring cord
6.7 4 Wood screws 6x80mm incl. screw anchors and washers
Width: 218 mm/8.58in
Height: 130 mm/5.12in
Depth: 92 mm/3.62in
