2.2.2 Camera Housing And Connectors
The MOBOTIX Q24M consists of the camera housing (motherboard and lens), the outer
shell and the mounting ring.
Connections
• NET (Ethernet network incl. PoE power supply)
• MiniUSB (e.g. for ExtIO)
• Slot for MicroSD card
Lens unit
Speaker
Microphone
(only Q24M-Sec)
LEDs
Slot for MicroSD card
(not externally accessible)
MiniUSB (e.g. ExtIO)
Bayonet catch
Network connector
L key
MxBus (for future
enhancements)
R key
