2.2.3 Q24M: Dimensions Without Mounting Options
Mounting Ring Drilling Template (Incl. Space For Wall Outlet)
ø 160mm/2.3in
48mm/1.89in
MxBus Netzwerk
Find the drilling
templates (scale 1:1)
at the end of the
manual as a fold-out
The blue circle indi-
cates the hole to cut
for the wall outlet
Note
Find the folded drilling template at the end of the manual.
Make sure that the drilling template is not scaled or adjusted to the paper size when
printing the PDF file (enlarged or reduced).
