Q24M Camera Manual: Installation
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
In-Ceiling Set (MX-OPT-IC)
For simple installation in false ceiling tiles.
Suitable for discreet surveillance. Optionally
available with a stainless steel ring.
Outdoor Wall Mount (MX-OPT-WH)
Consists of Outdoor Wall Mount and mount-
ing supplies. Covers RJ45 wall outlets. Space
for expansion modules (battery, UMTS,
WLAN, etc.) Easily mounted to poles using
Pole Mount. Weatherproof IP65.
Corner And Pole Mount (MX-OPT-MH)
Flange for Outdoor Wall Mount. Can be
mounted to wall corners or poles. 3 mm
stainless steel, white. Wall Mount may be
ordered separately or as a set.
Network Power Adapter Set (MX-NPA-PoE-Set*)
The Network Power Adapter Set allows
injecting the power supply for the MOBOTIX
Q24M into the network cable. This makes it
possible to use the network cable to both
connect the camera and remotely supply
power (up to 100m). The MOBOTIX Network
Power Adapter Set including power supply
with RJ45 connector is required if you do
not use a PoE compatible switch or router
to supply power to the MOBOTIX camera.
Can also be used as a
wall mount in drywalls
* Country-specic ver-
sions of the set are
available from MOBOTIX
(DE, US, GB, AUS, JP)
