Info Meaning Comment
State The port has to be activated.
Device Device definition This specification refers to the hardware interface of the
serial port. The normally used processor internal device
is: /dev/ttymxc0
Network Connection Mode and state The configured port mode is shown here followed by the
current state of the connection with IP and port of the
connected device.
Baudrate
Parity
Databits
transmission parameter These are the configured parameters of the serial
interface. Meaning: aaaa - b - c
aaaa = baudrate
b = parity (n = none, o = odd, e = even)
c = databits (7 or 8)
Serial Tx Frames/Bytes
Serial Rx Frames/Bytes
Network Tx Frames/Bytes
Network Rx Frames/Bytes
Net->Uart: Bytes in Buffer
Uart->Net: Bytes in Buffer
Statistical information These values shown here, inform us how many bytes or
data packets via the serial port has been sent or
received.
Table 6: Status der seriellen Schnittstelle
3.1.5 Relay Status Information (Optional)
In this section the current state of the relay is displayed. If the relay function is disabled, this section will not
appear.
Relay
Mode Function
TCP (UDP) The relay function is active and listening on the configured port
Internal The relay is controlled by the digital input.
serial Trigger The relay turns on when data is being received that is sent over the serial
interface. Thus, e.g. A wake-up function can be realized for the received
device connected to the MC. The relay switches off again if no data are sent
over the serial interface longer than "timeout".
Current State ON or OFF
Table 7: Relay status
3.1.6 Network Information
This section displays information on the active network interfaces.
The shown information depends on the configured bridge mode.
MC Manual Version 2.10c
