Advantages:
1. Any number of LAN clients can be connected to a MC.
2. Good transparency of the LAN clients to the WLAN without configuration.
Disadvantages:
1. The MC and all wireless clients work with their own IP addresses. These IP addresses must be in
the same network.
2. Problems in some WLAN infrastructures with centralized controllers (no accessibility to the LAN
clients from the WLAN side).
4.3 MWLC-Mode
With the MWLC mode, all restrictions on the availability, IP address assignment and transparency especially
in applications with multiple LAN clients are solved. In this Mode all data packets received from the LAN-
Clients are tunneled by the MC (Slave) to another MC (master) that is installed on stationary network side.
The master MC extract the LAN-Client data packets and send it into the stationary network.
MC Manual Version 2.10c
