_xxxx_ Numbering the file This is important if no time server is set up and the
MC is restarted.
_YYYYMMDD_ date of the recording Without time server, the clock will start at
01.01.2000
_hhmmss_ time stamp of the start Hour-minute second.
Without time server, the clock will start at
00.00.00
_uuuuuu time stamp of the start in micro seconds
From this list you can select one or more files and either download or delete them.
Both log and dump files are shown in the list, which are stored in the internal flash as well as in the possibly
installed USB stick. Files on the USB stick are marked with "(USB)".
7 Function of the serial interface
The most MC devices have a serial interface, which can be controlled via WLAN or LAN.
7.1 Parameters of the serial interface
These are the parameters of the serial interface:
Parameter Funktion Default
Port active Activation of the serial port off
Device Port address /dev/ttymxc0
Baudrate and format Setting the baud rate, data bits, stop bits and parity
handling
9600,8,n,1
Network configuration This is used to set the mode in which the serial interface
can be controlled via the network. You will find further
explanations in the next section
TCP-Server, 8888
Keep alive parameter Parameters for the TCP server or - client mode to
monitor the TCP connection. See the explanation below.
Send trigger
configuration
In order to avoid sending each individual serial-received character in a separate
network pack, 3 criteria for collecting and sending the characters are defined
1 Byte trigger Maximum number of characters to be
collected.
Default on : 16
2 Character timeout Definition of a maximum pause
between 2 characters in milliseconds.
If this time is exceeded, all characters
collected up to then are sent.
Default on : 100
3 Frame end trigger Definition of a character (as HEX
value) which leads to the sending of
the characters collected up to then.
Default off : 0D
Handshake mode Selection for the control of the handshake lines of the serial interface.
See the explanation below.
MC Manual Version 2.10c
