MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Main Status Parameters (continued)
The status screens can be seen when the UP or DOWN buttons are pressed on the main status screen. The following
table describes the menu parameters (NOTE: changes in shading indicates change to next screen by using the UP or
DOWN buttons):
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Output Status
(Page 2)
(Screen only visible
with Exhaust fan.)
Exhaust Fan: (If Enabled) Actual Value ON/OFF -
Exhaust Fan speed: (If Enabled) Actual Value 0-100 %
Demand Status
Cooling Demand: Actual Value 0-100 %
Heating Demand: (If Enabled) Actual Value 0-100 %
Hot Water Valve position: (If Enabled) Actual Value 0-100 %
Baseboard Heating: (If Enabled) Actual Value 0-100 %
BaseBoard Heat
Baseboard Heat Type: Actual Value
Analogue 0-10vDC
Digital 1 Stage
Digital 2 Stage
-
Baseboard Heat Demand: Actual Value 0-100 %
BaseBoard Heat
Digital Stage 1: Actual Value ON/OFF -
Digital Stage 2: (if Enabled) Actual Value ON/OFF -
Scheduler
Clock Override: Actual Value ON/OFF -
Override Time: Actual Value 0-4 Hours
Manual Control
Status
Unit in Manual: No No or Yes -
Reset Unit to Auto: Actual Value No or Yes -
On/Off Sub Menu
The following table describes the menu parameters (NOTE: changes in shading indicates change to next screen by using
the UP or DOWN buttons):
Main Status Screen = On/Off
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
On/Off Unit
Unit address Actual Value 1-32 -
Power by Display Off On or off -
Status Off By Keypad
WAITING
UNIT ON
OFF by pLAN
OFF by BMS
OFF by CLOCK
OFF by INPUT
OFF by KEYPAD
OFF by MANUAL
Unoccupied
Warmup
Occupied
Standby
-
On/Off Unit
(Screen visible only
With pAD Enabled)
pAD Address 1-32 -
On/Off Off
On
Off
Permanently Off
-
