MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Service Sub Menu (continued)
Main Status Screen = Service = Service Settings= Working Hour Setpoint
( requires password PW1)
Working Hour Setpoint
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Maintenance Hours Unit On
(When the run hours exceeds the setpoint an
alarm is generated but no other action is taken)
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Supply Fan
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Supply Fan High
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Compressor
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Compressor CCS
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Exhaust Fan
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
ERM Wheel
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Exhaust Air Vent Fan
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Maintenance Hours
Outside Air Vent Fan
Set Point: 0h 0-32,767,999 Hours
Reset to Zero? (resets run hours) No Yes or No -
Run Hours: Can be changed if required Actual Value 0-32,767,999 -
Probe Adjustment
Main Status Screen = Service = Service Settings= Probe Adjustment
( requires password PW1)
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Return Air
(As the probes (sensors) for each
component have already been listed ( see
“Analog Inputs”) only the Return Air is
detailed here but all sensors listed under
Analog Inputs have the same settings)
Input: B001 - -
Offset:
Calibration Offset
0 -99.9-99.9 °F / °C
Value:
The actual value after the
offset has been added
Actual Value - -
