MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Service Sub Menu (continued)
Main Status Screen = Service = Service Settings= User Save ( requires password PW1)
The following table describes the menu parameters (NOTE: change in shading indicates change to next screen by using
the UP or DOWN buttons):
User Save
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
User Save
Save? No Yes or No -
Restore? No Yes or No -
Enable Auto Save: Yes Yes or No -
Alarm History Reset
(This will clear the Alarm history)
Continue? No Yes or No -
Manual Management
WARNING
Improper control adjustments and manual mode
control can cause property damage, injury or death.
Read the installation, operating and maintenance
instructions thoroughly before making adjustments.
ATTENTION
The Manual Control has an automatic reset setting
located in the Service Settings under the Control
Settings.
Analog Input
Main Status Screen = Service = Manual Management = Analog Input
( requires password PW1)
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Analog Input Return Air
(As the analog inputs have
been listed under “inputs/
Outputs” section, Only the
Return Air sensor has been
detailed.)
Manual Control B001 Puts the input into manual mode Off ON/OFF -
Manual Position: Set the Manual Value for this input (only has
an affect when the input is in manual control, item above is
On).
0 -3276.8-3276.7 °F / °C
Value: If Manual Control is Off it is the actual value of the
Sensor, If Manual Control is On it is the value of the Manual
Position
Actual value -3276.8-3276.8 °F / °C
To Next Page
