MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Service Sub Menu
The following table describes the menu parameters (NOTE: changes in shading indicates change to next screen by using
the UP or DOWN buttons):
Main Status Screen = Service = Information
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
INFORMATION
Code (Name of Program) Actual Value - -
Ver. (Software Version) & Date Actual Value - MM/DD/YY
Bios Version & Date Actual Value - MM/DD/YY
Boot Version & Date Actual Value - MM/DD/YY
INFORMATION
PAGE 2
pCO Type pCOOEM+ - -
FLASH Actual Value - Kb
RAM Actual Value - Kb
FLASH 2 Actual Value - Kb
FLASH 3 Actual Value - Kb
Memory Type Actual Value - Mb
T Memory Writes Actual Value - -
Main Cycle Actual Value - Cycles/s
INFORMATION
(Power Cycle Status)
PAGE 3
Last Off Time Actual Value -
MM/DD/YY
HH:MM:SS
Last On Time Actual Value -
MM/DD/YY
HH:MM:SS
Length Time Off Actual Value - Days/Hrs./Min.
Information
Control Power Status
Voltage Actual Value - Voltage
Current Actual Value - Current
Information
EVO
Fw Version: Actual Value - -
Service Version: Actual Value - -
Information
Main Status Screen = Service = Working Hours
Working Hours
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Run Hours
Unit ON
Run Hours Actual Value 0-32,767,999 Hours
Number of Starts Actual Value 0-32,767,999 Starts
Run Hours
Supply Fan Actual Value 0-32,767,999 Hours
Supply Fan High Actual Value 0-32,767,999 Hours
Run Hours
Compressor Actual Value 0-32,767,999 Hours
Comp. CSS: Actual Value 0-32,767,999 Hours
Run Hours Exhaust Fan Actual Value 0-32,767,999 Hours
Run Hours ERM Wheel Actual Value 0-32,767,999 Hours
Run Hours
Exhaust Air Vent Fan: Actual Value 0-32,767,999 Hours
Outside Air Vent Fan: Actual Value 0-32,767,999 Hours
