MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Clock/Scheduler Sub Menu
NOTE: The schedule/holidays can b used to either turn the unit On/Off or to cycle the unit from Occupied to Unoccupied.
The following table describes the menu parameters (NOTE: changes in shading indicates change to next screen by using
the UP or DOWN buttons):
Main Status Screen = Clock/Scheduler
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
Clock
Date: Actual Date MM/DD/YY -
Hour: (Military Time) Actual Time 00:00-23:59 Hrs:Min
Day Actual Day (Calculated) MTWTFSS -
Scheduler Number of Schedules 0 0-7 -
Scheduler
(This Screen is repeated
based on number of
Schedules Selected)
Schedule #: Actual Value 1-7 -
Time On: 00:00 00:00-23:59 Hrs:Min
Time Off: 00:00 00:00-23:59 Hrs:Min
Days Enabled: none MTWTFSS -
Holidays Number: 0 0-16 Days
Holidays
(Screen will show only
if 1 or more holidays are
selected)
Holiday 1 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 2 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 3 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 4 Start - Stop 00/00-00/00 1/1-12/31 Days
Holidays
(Screen will show only
if 5 or more holidays are
selected)
Holiday 5 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 6 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 7 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 8 Start - Stop 00/00-00/00 1/1-12/31 Days
Holidays
(Screen will show only
if 9 or more holidays are
selected)
Holiday 9 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 10 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 11 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 12 Start - Stop 00/00-00/00 1/1-12/31 Days
Holidays
(Screen will show only if
13 or more holidays are
selected)
Holiday 13 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 14 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 15 Start - Stop 00/00-00/00 1/1-12/31 Days
Holiday 16 Start - Stop 00/00-00/00 1/1-12/31 Days
Clock
DST: (daylight Savings Time) On On / Off -
Transition Time: 60 0-60 Minute
Start: (Date placement in month) Last Last, 1st-4th -
Start: (Day) Sunday Mon-Sun Day
Start: (Month) March Jan-Dec Month
Start: (Time) 2:00 0-12 Hour
End: (Date placement in month) Last Last, 1st-4th -
End: (Day) Sunday Mon-Sun Day
End: (Month) October Jan-Dec Month
End: (Time) 3:00 0-13 Hour
