MODINE CONTROLS SYSTEM MANUAL
ClassMate and SchoolMate Models
AIR74-525.1
Model Nomenclature - SchoolMate
1,2 - Product Type (PT)
SM - SchoolMate
3 - Unit Configuration (UC)
G - Ground Source
W - Water Source
4,5 - Nominal Capacity (MBH)
24 - 24,000 Btu/Hr
30 - 30,000 Btu/Hr
36 - 36,000 Btu/Hr
42 - 42,000 Btu/Hr
48 - 48,000 Btu/Hr
60 - 60,000 Btu/Hr
6 - Supply Voltage (SV)
B - 208/60/1
C - 230/60/1
D - 208/60/3
E - 230/60/3
F - 460/60/3
G - 575/60/3
H - 277/60/1
7 - Generation (G)
A - Current Design
8 - Control (C)
M - Modine Control System
F - Factory Installed Free Issue
B - By Others - Field Installed
9 - Ventilation Configuration (VC)
No Exhaust
A - Economizer
B - Economizer with OA Damper
Z - Return Air Only
Gravity Exhaust
F - Economizer
G - Economizer with OA Damper
H - ERV with OA Damper
J - ERV with OA Damper & Economizer
K - ERV with OA & RA Damper & Economizer
Powered Exhaust
L - Economizer
M - Economizer with OA Damper
N - ERV with OA Damper & Economizer
P - ERV with OA & RA Damper & Economizer
10 - Filtration (F)
A - MERV 8
B - MERV 11
C - MERV 13
D - MERV 16
11 - Case Construction (CC)
A - 20Ga (Standard)
B - 16Ga
S - STUDY Package 20Ga
12 - Door Mounted Stat (DS)
N - None
V - Vertical Stat
H - Horizontal Stat
13 - Door Mounted Other (DO)
N - None
K - Key Over-ride
S - Occupancy Sensor
L - Indicator Light
T - Twist Timer
14 - Dehumidification (D)
N - None
A - HGRH Coil
15,16 - Heating Option (HO)
00 - None
02 - 2 kW (1-stage)
03 - 3 kW (1-state)
04 - 4 kW (1-stage)
05 - 5kW (1-stage)
08 - 7.5 kW (1-stage)
09 - 9kW (1-stage)
10 - 10 kW (2-stage)
12 - 12kW (2-stage)
15 - 15 kW (2-stage)
18 - 18 kW (2-stage)
20 - 20 kW (2-stage)
81 - 1R HW Coil (1/2") - Bottom Connection
82 - 1R HW Coil (3/4") - Bottom Connection
83 - 2R HW Coil (1/2") - Bottom Connection
84 - 2R HW Coil (3/4") - Bottom Connection
91 - 1R HW Coil (1/2") - Top Connection
92 - 1R HW Coil (3/4") - Top Connection
93 - 2R HW Coil (1/2") - Top Connection
94 - 2R HW Coil (3/4") - Top Connection
17 - Coaxial Coil Option (CO)
1 - Copper (Standard Bottom Pipe Connections)
2 - Cupro-nickel (Standard Bottom Pipe Connections)
3 - Copper (Top Pipe Connections)
4 - Cupro-nickel (Top Pipe Connections)
1,234,56789101112131415,16 17
PT UC MBH SV G C VC F CC DS DO D HO CO
