Service Sub Menu (continued)
The following table describes the menu parameters (NOTE: changes in shading indicates change to next screen by using
the UP or DOWN buttons):
Main Status Screen = Service = BMS Configuration
BMS Configuration
SCREEN NAME PARAMETER DESCRIPTION FACTORY VALUE RANGE UNITS
BMS Configuration
(Modine Control System Supports the Following
Protocols:
Lon
BACnet IP/Eth
BACnet MSTP)
BMS CARD Protocol: BACnet MSTP
Lon
BACnet IP\Eth
BACnet MSTP
PCOLOAD
MODBUS EXT
MODBUS
MODEM
CAREL
-
BMS PORT 2 Protocol PCOLOAD
Lon
BACnet IP\Eth
BACnet MSTP
PCOLOAD
TH-TUNE
MODBUS EXT
CAREL
-
BMS Configuration (Page 2)
(Select “YES” to Change BACnet IP/Eth and
BACnet MSTP Settings)
Termconf PlugIn? No
No
Yes
-
BMS Configuration
Enable heartbeat: No No/Yes
Thresholds: 5 0-999 -
Timeout: 300s 0-9999 s
Period: Actual Value 0-999.9 s
BMS Configuration If BMS Offline turn unit: Off On/Off -
MSTP SETUP
(Screen only Visible When BACnet MSTP is
Selected and Termconf Plugin is Enabled.)
Instance 0 0-4194999 -
Baud rate N/A
N/A
9600
18200
36400
76800
bps
MAC Address: 0 0-127 -
MaxMasters: 0 0-127 -
MaxInfoFrames: 0 0-99 -
TCP/IP Setup
(Screen Only Visible when BACnet IP/Eth is
Selected and Termconf Plugin is Enabled.)
Instance: Actual Value 0-99,000 -
IP: Actual Value 0.0.0.0-255.255.255.255 -
SubNet: Actual Value 255.0.0.0-255.255.255.0 -
Gateway: Actual Value 0.0.0.0-255.255.255.255 -
TCP/IP Setup (Page 2)
(Screen Only Visible when BACnet IP/Eth is
Selected and Termconf Plugin is Enabled.)
DNS 1 Actual Value 0.0.0.0-255.255.255.255 -
DNS 2 Actual Value 0.0.0.0-255.255.255.255 -
Type Actual Value IP, Ethernet -
BACnet Read/Write
Function: Read Read/Write -
Update? No No/Yes -
Bms Configuration
Heartbeat Select: No No/Yes -
Heartbeat Delay: 120s 0-999 seconds
Heartbeat Active: Actual Value No/Yes -
To Next Page
