Page #48 background imageLoading...
Page #48 background image
Topology Configuration
46
04/99 AWB 2700-1311 GB
Receive data:
Number of data bytes that the slave is to receive from
the master. The number of receive data bytes must
match the set number of send data bytes from the
master.
Send data:
Number of data bytes that the slave is to send to the
master. The number of send data bytes must match
the set number of receive data bytes of the master.
Remote Control:
Check the box if the slave is to switch between “Halt”
or “Run” simultaneously with the master.
Receive/send data bytes are always defined from
the point of view of the device for which the
configuration is created. The number of possible
send/receive data bytes have the following limits:
Send/Receive data Bytes
Max. number of send data bytes (Output) per station 120
Max. number of receive data bytes (Input) per station 120
Max. total number of send / receive data bytes
(Output/Input)
784
H1311g.bk Seite 46 Freitag, 4. Juni 1999 1:12 13
