Operation
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
3.3.6 Service Diagnostic
The following Service Settings are adjustable by the Authorised Service Agents:-
Press the Programming Key ‘P’ for 3 seconds to access the Service Menu.
The programming light ‘Prog’ will illuminate.
The display screen will show the following service menu settings:-
1. Proofer Settings.
2. Recipe.
3. System.
4. Service.
5. Exit.
Use the ‘Up’ / ‘Down’ scroll keys to scroll through the service menu settings.
Select No.4. ‘Service Settings’ and press the Programming Key ‘P’,
Press the Proofer # 2, Oven # 3, Proofer # 2, Proofer # 3 keys, then press Program-
ming Key ‘P’ Service Setting screen will display.
Use the ‘Up’ / ‘Down’ scroll keys to scroll through the service menu settings. Press the
Programming Key ‘P’ to select ‘Diagnostic’.
The temperature reading for the Oven Probe screen will display
Use the ‘Up’ / ‘Down’ scroll keys to scroll through the service menu.
The temperature reading for the Proofer Air Probe screen will display
The temperature reading for the Proofer Water Probe screen will display.
The status of the oven door microswitch will display.
The status of the proofer water tank float switch will display.
