Replacement Parts
Revision 3
© Moffat Ltd, September 2009
E32SUBC OVEN and PROOFER
8.1.2 Oven Door
Item No. Part No Description
1 024713 HANDLE WA
2 026184 DOOR OUTER WA SUB
3 090201 SIL.EXTR Y DOOR SEAL 1.74m
4 090415 DOOR INSULATION
5 2340 DOOR GLASS
6 026187 GLASS CLAMP ANGLE
7 5019 DOOR INNER WA SUB
8 024809 ROLLER CATCH ASSY
9 020082 TOP HINGE ASSY
10 020083 BOTTOM HINGE ASSY
