1.1 Used signal words and notes
1.2 Intended use
1.3 General safety notes
1 Safety
Warning
Electrical voltage! Danger to life!
The base station is live.
¾ Always disconnect from the mains network and secure against unintended activation before
opening it.
¾ Disconnect external voltages existing at the pump and the boiler contact and secure against
unintended activation.
Emergency
¾ In case of emergency, disconnect the complete single room control system.
Retain this manual and provide it to future owners.
The following symbols show you, that
¾ an action must be performed.
9 a precondition must be met.
Warning
Electrical voltage! Danger to life!
The shown symbol warns against electrical voltage. Warning notes are highlighted with
horizontal lines.
The base stations Radio 24 V and 230 V of the type BSF x0xx02-xx serve
9 for the arrangement of a single room regulation system (readjustment) with a maximum of
12 zones (depending on the type used) for heating and cooling systems,
9 for the connection of a maximum of 18 actuators and 12 room control units (depending on
the type used), a pump, a CO signalling unit, a humidity sensor with potential-free contact as
well as an external timer,
9 for a fixed installation.
Every other use is considered as not intended; the manufacturer cannot be held liable for this.
Modifications and conversions are expressively forbidden and lead to dangers the manufacturer
cannot be held liable for.
