HarshIO 600 eIP

21

IP67 Digital I/O Modules for EtherNet/IP
Mechanical
Housing dimension
600 x 220 x 20 mm (2.36"x8.66"x.780")
Housing material
PBT VALOX 420 SEO Black 7701
Flammability Standard
UL 94 V-0
Corner mounting hole
4 mounting holes, 5 x10 mm
Central mounting hole
1 mounting hole,  4.45 mm
Ground stud
Yes, stainless steel (allows the continuity of the ground when the module is mounted on the chassis
machine)
Operating temperature
-25°c … +70°c
Storage temperature
-40°c … +90°c
Vibration resistance
7G (15,7Hz to 500Hz), 3 axis
Shock resistance
15g, 11ms, 3 axis
Electro-magnetic compatibility
EN 61000-6-2 / EN 61000-6-4
Relative humidity
10 % to 95 %, non-condensing
Protection Class
IP67
Approval
CE (according IEC 61131-2), UL / cUL
Environmental
RoHS and REACH
MTBF
100 000 hours / 11 years at 70°C
