HarshIO 600 eIP

20

IP67 Digital I/O Modules for EtherNet/IP
Fieldbus
Ethernet connectors
M12, 4-pin, female, D-Coded, stainless steel, shielded
IP setting
DHCP based on MAC (infinite lease), Static IP
Protocol
EtherNet/IP Adapter according specification Vol 1-3.9 (CIP) and Vol 2 – 1.10 (EtherNet/IP)
Data access
Implicit messages for I/O data transfer
Implicit (I/O) connection
 1x Exclusive Owner (EO) connection (with or without configuration data)
 Up to 7 Listen Only (LO) or Input Only (IO) connections (with or without configuration data)
Explicit (EM) connection
 Up to 8
Supported CIP Objects
 0x01 – Identity object
 0x02 – Message Router object
 0x04 – Assembly object
o 103: TO (Input process data)
o 104: OT (Output process data)
o 106: Configuration
o 198: OT Heartbeat (Input Only)
o 199: OT Heartbeat (Listen Only)
 0x06 – Connection Manager object
 0xF5 – TCP/IP Interface object
 0xF6 – Ethernet Link object
Integrated Switch
 2x ports integrated switch
 Speed: 10/100Mbps
 Auto negotiation
 Auto crossing
 Auto polarity
 1x status Led / port
 Storm Protection against network loop (Broadcast, Multicast and Unicast packets)
Daisy Chain (Ethernet)
Up to 8 HarshIO
Ethernet Packet
Manage up to 9000 packet/sec
Request Packet Interval (RPI)
from 1 ms up to 65535 ms (default 30 ms)
IP Address Conflict Detection
Yes (ACD supported)
Quick Connect
Yes (Class A)
ODVA conformance
Yes
Default IP setting:
IP address: DHCP
Subnet mask: DHCP
Gateway: DHCP
ETH1 port: Auto negotiation + Auto-MDI
ETH2 port: Auto negotiation + Auto-MDI
Quick Connect: Disabled
ACD Enabled
