HarshIO 600 eIP
30
IP67 Digital I/O Modules for EtherNet/IP
16 Outputs module versions
Byte
Offset
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Input Data (Assembly #103), Size: 8 bytes
Data
00
n/u
n/u
n/u
n/u
n/u
n/u
Diag
UB
n/u
Diag
UL
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Input Data
02
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Port Status
04
CS O7
CS O6
CS O5
CS O4
CS O3
CS O2
CS O1
CS O0
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Port Status
06
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
CS
O15
CS
O14
CS
O13
CS
O12
CS
O11
CS
O10
CS
O9
CS
O8
Output data (Assembly #104), Size: 4 bytes
00
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Output Data
02
O15
O14
O13
O12
O11
O10
O9
O8
O7
O6
O5
O4
O3
O2
O1
O0
Configuration (Assembly #106), Size: 16 bytes
Data
00
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
02
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
04
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
06
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
08
n/u
n/u
n/u
n/u
n/u
n/u
n/u
QC
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
10
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
12
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
14
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u: Not used
CS: Channel status (short circuit on Output channel or impossible to drive the Output)
If output power supply (UL) is down, output channel status (CS) is set for the corresponding activated
output channels. The module display shows the message:”IO: ERR”.
Example: if the output “O3” is active and UL goes down, the “CS O3” status bit is set to 1.
Ox: Output channel x
QC: Quick Connect, 1 = Enable; 0 = Disable
Diag UB: Diagnostic Logic/Input power supply (UB)
Set to 1, if UB is < 14.1 VDC
o All Outputs activated are de-energized
o All Outputs activated have diagnostic leds to RED
o All Outputs activated have Port Status (CS Ox) bit set to 1
Set to 0, if UB is > 14.6 VDC
o All Outputs activated are energized
o All Outputs activated have diagnostic leds to GREEN
o All Outputs activated have Port Status (CS Ox) bit set to 0
Diag UL: Diagnostic Output power supply (UL)
Set to 1, if UL is < 17.6 VDC
o All Outputs activated are de-energized
o All Outputs activated have diagnostic leds to RED
