Moons' M2 Series - Signals Description of Connector CN2; The Layout of CN1 Connector; Input Signals

17
Rev. 1.0
4/29/2016
M2 Quick Setup Guide Manaul
3.7.2 Signals Description of Connector CN2
3.7.2.1 The Layout of CN1 Connector
A
B
View AView B
3.7.2.2 Input Signals
M2 series AC servo drive have 12 programmable digital inputs as well as 2 analog inputs.
Each of the input can be specified with different function via parameter settings. The functions are
as follows:
◆
Specified function signals: i.e. Pulse/DIR signal, motor enable/disable signals.
◆
General purpose signal: In velocity mode, torque mode, Q program mode, or SCL mode,
