Moons' M2 Series Quick Setup Guide Manual

5
Rev. 1.0
4/29/2016
M2 Quick Setup Guide Manaul
1 Product Description
1.1 Unpacking Check
Please refer to this section to confirm the model of servo drive and servo motor .
A complete and workable AC servo system should include the following parts:
1. Matched Servo drive and Servo motor
2. A power cable connect the drive to the servo motor(Option)
3. An feedback encoder cable connect the drive to the motor (Option )
4. A mini USB cable connect the port CN1 to PC for communication.(Opti
on)
5. 50-PIN connector (For I/O connections, Port CN2) Option
6. 26-PIN connector(For encoder feedback,Port CN3 ) Option
7. 6-PIN connector(IEEE1394,Option)
8. RJ-45 connectors (For RS-485 or CANopen communication,Port CN6 adn CN7)Option
9. 5-PIN connectors (For L1,L2,L3,L1C,L2C)
10. 6-PIN connector(For U,V,W,B1+,B2,B3)
1.2 Servo Drive Model Introduction
1.2.1 Drive Name Plate Description
Model No.
Input/Output Voltage
Phase
Rated Current
Frequency
Rated Power
1.2.2 Drive Model Description
M2DV -
□ □ □
2
□
***
M2 Series AC Servo Drive
If Applicable
Current
Code
Continuous
Current (RMS)
Boost
Current (RMS)
1D8 1.75A 5.25A
3D0 3.00A 9.00A
4D5 4.50A 13.50A
Voltage Code Input Voltage
2
Single/Three-Phases200~240VAC
±
10%, 50/60Hz
Communication
Type
Configuration Description Communication
S
Mini USB
Basic Type
- - -
Q
Q Type
RS-232
R
Q Type(Modbus/RTU Type)
RS-485
C
CANopen Type
CANBus
IP
EtherNet/IP
Type
EtherNet
E
eSCL
Type
EtherNet
