M2 Quick Setup Guide Manaul
8 Conguration by Personal Computer
in order to ensure servo drive and motor meets your operation requirements, we strongly
recommend customers to use
“
M servo suite
”
for following configuration setups:
1. Servo Motor model selection and configuration
2. Operational mode selection
3. Define drive
’s input/output mode
4. Apply auto tuning function on PID parameters for optimized motor performance.
Connect to Personal Computer
MODE SET
安装M2 Servo Suit设置软件
请到本公司网站下载
www.moons.com.cn
Interface of M2 Servo Suit
Configuration Steps Details
Step 1 Motor Configuration
Step 2 Select Control Mode
Step 3 Further configuration 1
Step 4 Further configuration 2
Step 5 I/O configuration
