Morbark BEEVER M12RX - Page 31

Forward
pulls material into
the feed wheels
Stop
stops movement
of the feed wheels
Stop
stops movement
of the feed wheels
Reverse
pushes material out of
the feed wheels
76347-385 • 06-15
2.7
After Engine warm-up: Auto Clutch
1. Position the throttle in acceleration mode. Keep it at this speed during the
chipping process.
2. Begin loading the brush. (see next page).
Engage clutchDisengage clutch
The Chipping Cycle • Start-up
Figure 2.6
Clutch
Figure 2.5
