Morbark BEEVER M12RX - Hydraulic Oil and Fuel Tank

3.18
,
,
®
76347-385 • 06-15
Figure 3.7
Hydraulic oil
filler cap
Hydraulic oil
vent cap
Fuel
filler cap
Hydraulic oil filter
Sight gauge
Sight gauge
*Feature varies depending on the model you have ordered, see the options tabs for details on your model.
Hydraulic Oil and Fuel Tank
Inspection cover
Fuel tank
Hydraulic
oil tank
Features and Function • Components • Hydraulic Oil and Fuel Tank
