76347-385 • 06 -15
4.4
Lubricating the machine is vital to its operation. There are many points of lubrication on the machine. These include the wheel axle, feed wheel bearings,
yoke cylinder pins, yoke pivot pins, clutch, discharge chute swivel and crank handle, chipper drum bearings, control bar, and battery box.
Lubricate the grease points as outlined on the schedule below.
NOTE: The following maintenance intervals apply for normal operating conditions only. Intervals are hours of operation based on 8 hours per day, 5 days per
week. If your operating conditions are difficult, adjust the specified intervals.
Lubrication
General Maintenance • Lubrication
Key:
X = 1 shot of grease (Use only EP rated grease)
Description
Number of
locations
Start
up
8
hours
40
hours
Wheel axle 2 See OEM manual
Feed wheel bearings 2 X
Yoke pivot pin 2 X
Clutch 4 See OEM manual
Discharge chute swivel 2 X
Chipper drum bearings 2 X
Control bar 2 X X
Battery box 2 X
Table 4.2 • Routine Lubrication Schedule
