Function
The hydraulic valve bank controls operate the machine. The auto reverse
valve stops the feed wheel when low RPM’s are detected from the motor. It
allows for smooth shifts in direction (forward or reverse) of the feed wheels.
Maintenance
• Check fittings and hoses for leaks
• Check coils for tightness
• Check for wear on wiring
WARNING!
Relieve stored hydraulic pressure before
performing service to the hydraulic system.
Components could be hot to the touch.
