Morgana DIGIFOLD - Example of Set by Position

PaperLength=350mm
FeedDirection
LeadingEdge
Cr1 Cr2 Cr3
F1 F2
Cr1=97.0mm
Cr2=179.0mm
Cr3=260.0mm
F1=179.0mm
F2=260mm
Alldimensionsarefromtheleadingedgeofthepaper
ExampleofSetbyPosition.
Cr2
F1
9mm
FirstFold
SecondFold
LeadingEdge
Cr3
F2
=179.0
=260.0
FinishedDocument
9mm
LeadingEdge
9mm
LeadingEdge
SETTINGS
OperatingtheDigifold
Page16
CREASING/FOLDING
