Morgana DIGIFOLD - Adjusting the Papergate

OperatingtheDigifold
AdjustingthePaperGate
Thestandardsettingforhorizontaladjustmentofthepapergateis6.5mm(1/4")away
fromthemountingblock.TurndiscJtomakethisadjustment.Thissettingisonlyintended
asaguide,forinstance,sheetswithanupwardcurlwillrequirethissettingtobe
increased.SettheheightofthePaperGatetoapproximatelytwothicknessesofpaper,by
turningknobK.Anexcessivegapisamostlikelycauseofdoublesheetfeeding.
J
K
6.5mm(1/4")
T WO T HICKNESSES
OF PAPER
WARNING.
DO NOT ADJUST T HE
PAPER GAT E WHILE T HE
MACHINE IS RUNNING OR
T HE SUCT ION DRUM MAY
BECOME DAMAGED.
Setingthesuctionslot
.
t
SettingtheAdjustableSideLay
Thesuctionslotislocatedinsidethevacuumrollerandcanbeadjustedbyreleasingand
movingthesuctionknobhorizontallyineitherdirectiontotherequiredposition.
Forlightstockssettheknobtotheleftandforheavierstockssettheknobtotheright
Placethepaperstackontotheloadingtableandslideuptothefixedsidelayandpaper
gate.Releasetheclampslocatedateachendofthesidelayandslideuptowardsthe
paperstackasshowninFIG16.1.Allowagapofapproximately0.5mm(1/64inch)between
thepaperandthesidelay.
Adjustable
SideLay
Page17SYSTEM
Digifold
