Morgana DIGIFOLD - Control Panel Features; Button and Switch Operations

FeaturesontheControlPanel
PushButton1
PushButton2
PushButton3
PushButton4
Set-upswitch
Settingdial
Suctionswitch
Feedswitch
Systemswitch
Compressorswitch
Usedforadjustingacrease/foldpositioninincrementsof10mmwhenusedwith
thesettingdial.
Alsousedforinchingfeedforwardwheninhandleorcrunch/Clip1orClip2
situation.
Usedforadjustingacrease/foldpositioninincrementsof0.1mmwhenusedwith
thesettingdial.
Usedforlocatingthebottombladeoranviltoits‘TopDeadCenter’positioninorder
tosetthebladepressure(whilstthesystemswitchison).
Alsousedtoreturnthecreaserbladetothe‘Home’positionaftera‘Crunch’if
required.
Allowstheoperatortosaveacreatedprogram.Whenalsousedwiththesetting
dialtheoperatorcanscrollthroughthestoredmemoryaddresses.
Alsousedforcyclingthefolderblade/feedforward.
Allowstheoperatortoenterandsubsequentlyeditorreadastoredprogram.Also
resetsthebatchquantity.
Allowstheoperatortoscrollthroughstoredmemoryaddressesandprograms,
increaseordecreasethebatchquantityandsetacrease/foldposition.
Allowstheoperatortovarythelengthofsuctiononthesheetofpaperbeingfed.
PositionIForveryshortsheets.
PositionIIForshortnon-standardsheets.
PositionIIIForallstandardsizesheets,generalpurpose.
Allowstheoperatortostartandstopfeedingsheets.
Whenactivatedthesystemswitchwilloperatethemotorsinordertobeginthe
creasing/foldingsequence.
Allowstheoperatortoswitchoffthecompressorunitinordertoutilizethemachine
tomanuallyfeedsheets.
Alsousedforinchingfeedinreversewheninhandleorcrunch/Clip1orClip2
situation.
TheControlPanel
Page7SYSTEM
Digifold
