Morgana DIGIFOLD - Trouble Shooting: Paper Issues; Paper Crease or Fold Out of Square; Paper Jamming

Papercreaseoutofsquare
Paperjamming
!
!
!
!
!
Checkthatthesheetsareallsquareandexactlythesamesizebeforeloadingthe
stackontothetable.
Checkthattheadjustablesidelayhasbeencorrectlypositionedie.Nofurtherthan
0.5mmfromthepaperstack.
Checkthatthebladeisaslidefitinthesideplateslots,adjustifnecessary,see
adjustingbladealignment.
Checkthattheleadingedgeofthepaperisnotbeingdamagedbythepapergate.If
thisisoccurring,checkthatthesuctionslotandthepapergatehavebeencorrectly
set.
Checkthatthefirstcrease/foldpositionisnottooclosetotheleadingedgeofthe
paper.Aminimumdistanceof40mmisrecommended.
Paperfoldoutofsquare
Machinewillnotstart
Note:-thebestfoldsquarenessisachievedwhenthefoldisnotonthecenterofthe
crease,buttoonesideortheother.
Checkthatthefoldistoonesideofthecreasecenterline.
Checkthattherollergapisnottootightandsquashingthecrease.
Checkthattherollergapisnottoolargeandallowingthepapertoslide(especially
soonglossypaper).
Checkthattherollersarenotwornononeend.
Ifjammingisoccurringintheoutfeedrollers,openuptherollergap.(Seepage21)
Checkthepowersupplytothemachine.
Checkthattheemergencystopbuttonhasbeenreleased.
Checkthatthetwotopguardsaredown.
Checkthatthedeliveryunitisfitted,andlocatedcorrectly,(themachinewillnotstart
ifthedeliveryunitisnotfitted).
Checkthatthelowerblade/anvilisconnectingtothehomeswitch(mountedbelow
thelowerblade/anvil).
!
!
!
!
!
!
!
!
!
!
TroubleShooting
Page29SYSTEM
Digifold
