TroubleShooting
CrackingofthePrintedMaterialalongtheCrease.(continued)
Papermarkingorscratching.
Setting‘F_cLr’tothe‘on’position.
Nosuction
DisplayWindowReads
!
!
!
!
Whenusingdryinkortonerbasedprintengines,thematerialbefully
acclimatisedforatleast48hoursbeforeputtinganimageontothepaper.
s
must
IMPORTANTNOTE.
Ifthepaperismarkingorscratchingset‘F_cLr’to‘on’,asdescribedbelow.
Thisfunctionisusedtowithdrawthetopfoldbladefromthenipposition,whenpaper
isinthefoldroller.Thisreducesthepossibilityofmarkingorscratchingsensitive
paper.Oncertainfolds,gatetypesforinstance,‘F_cLr’shouldbesetto‘off’because
thetrailingedgeofthepaperwillcatchonthewithdrawnblade.
IfF_cLr’hasbeensetto‘on’,anysubsequentchangetotheprogrammesettingswill
automaticallyreturn‘F_cLr’backtoitsdefaultsettingof‘off’;anditmustthereforebe
etbackto‘on’again.
1.Selectthemaindisplayscreen(seepages11and13toidentifymaindisplay).
2.SettheSetUpswitchtoitsMid-position.
3.TurntheSettingDialclockwiseuntilthedisplayreads‘F_cLr’.
4.FlicktheSetUpswitchupwardstoselect‘on’.
Iftherollersaremarkingthemedia,opentherollergap(seepage21).
Ifthesuctiondrumisnotrotating,checkallofthedrivebeltsforcleanlinessandsplits
(includingthebottomin-feedrollerdrivebelt).
! ‘h’
Ifatanytimeduringthecreasing/foldingprocessthedisplaywindowreads,itis
indicatingthatthelowerblade/anvilhasnotmadecontactwiththeHOMEswitch.
i.e.Bladestillintopposition.Switchthemachineoffandremovethebladeset,
ensurethattheareaisfreefromobstructions.Returnthebladesettothecreasing
unitandswitchthemachineon.Operatethemachineinthenormalsequence,ifthe
lettercontinuestoappearitisadvisedtocontactaServiceEngineerimmediately.
‘h’
’h’
