OperatingtheDigifold
SettingtheBack-Stop
SettingtheAirDistribution
SettingtheAirSeparationPressure
Settingthepositionsofdrivewheelsandhubs
Placetheback-stopontotheadjustablesidelayandslideuptowardsthepaperstack
allowingagap(asspecifiedintheabovestep)beforeclamping.Whentheextensiontable
isusedforfeedinglongersheets,removeclamptypebackstopandusethemagnetic
typebackstopasshowninfig.18.2.
Dependingonthelengthofthesheettobecreased,theairdistributionknobcanbe
rotatedtovariouspositionsinordertosupplyairtodifferentports.Position1is
recommendedformostsheetsizes.However,abetterresultmaybeobtainedbyusing
thebelowsettingsorbyexperimentation.
1-ForA5sheetsor8incheslong,port1open.
2-ForA4sheetsor11incheslong,frontportandport2open.
3-ForA3sheetsor17incheslong,frontportandport3open.
0-Forlongersheetsinordertosupplyairtothecentreofthestack,port
2open
Tocontroltheamountofairsuppliedtotheports,theairseparationknobcanberotated
clockwisetodecreasethepressureoranti-clockwisetoincreasethepressure..
Itisimportantthatthedrivewheelsanddrivehubsontherollershaftsarearrangedevenly
acrossthewidthofthemediabeingcreased.Thisisdonetoensurethatthemediais
accuratelydrivenandsupportedthroughtherollers.
Thedrivewheelsandhubsarefixedtotherollersbymeansofagrubscrew.Tolocatethis
grubscrewtherollerscanberotatedbyoperatingthemotormanually.
Position
DONOTROTATETHEDRIVEROLLERSBYHAND.
Page18
CREASING/FOLDING
