ThedeliveryunitontheDigifoldisusedtocatchthesheetsoncetheyhavebeen
creased,orfolded.
1.Hookthedeliveryunitontotheshaftinthepositionsshownbelow,beingcarefulto
alignthematingconnectors.
2.LocatetheSupportHoopintothechannelontheundersideofthedeliveryunit.
WARNING:-
TheDigifoldwillstartifthedeliveryunitisnotfittedontothemachine.not
AssemblethedeliveryunitasshowninFIG23.1.
TheDeliveryUnit
FIG23.1
DeliveryUnit
LocationHooks
HookstobeLocatedontoshaft
inthesepositions
SupportHoop
Connector
