2.7.2
Charging with the AC Adapter
The AC adapter is an optional add-on for the L6Q Installation Kit and may not be included.
Procedure:
1 Connect the M12 elbow connector from the AC adapter to the lower port on the back of the
camera and screw down the connector sleeve to secure.
2 Power the unit from a standard AC wall outlet.
2.7.3
Charging with the DC Adapter
The AC adapter is an optional add-on for the L6Q Installation Kit and may not be included.
Procedure:
1 Connect the M12 elbow connector from the AC adapter to the lower port on the back of the
camera and screw down the connector sleeve to secure.
2 Power the unit from a 12V DC power source.
MN008660A01-AC
Chapter 2 : Pre-Installation
27
