Level 1 and 2 Service Manual Part Numbers
A1000 Exploded View Parts List
To order parts use the following link:
https://wissc.motorola.com/wissc_root/main/BrowserOK.html
(Password is Required)
For information on ordering parts contact EMEA at +49 461 803 1638.
Table 8. A1000 Exploded View Parts List
Item
Motorola
Part No.
Description Item
Motorola
Part No.
Description
1 SHN9737A Battery door assembly 12 0587239Y01 Grommet, Camera
2 SNN5697A Battery 13 1590039N02 Front Endo Upper Assembly
3 SHN9738A Stylus 14 2690180N02 Elastomeric Shield
4 0387340Y01 Screws (8x) 15 7289439N02 Display Assembly
5 1590089N01 Rear Housing Assembly 16 1590041N02 Front Housing Assembly
6 3887320Y01 Side Button 17 3889966N03 Navigation Keypad
7 0387340Y01 Screws (2x) 18 3889967N01 Gaming Keypad
8 1589973N01 Rear Endo Upper Assembly
9 8488485N01 Transceiver Board
10 0189905N01 Camera Assembly
11 1589959N01 Front Endo Lower Assembly
E
The Lithium ion battery pack may explode if replaced incorrectly. Replace only with
the same type of battery or equivalent as recommended by the battery manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
