Motorola A1000 Service Manual

6809490A77-O October 4, 2004 5
Level 1 and 2 Service Manual Specifications
Specifications
1
UTRA Absolute Radio Frequency Channel Number (UARFCN)
2
All talk time and standby times are approximate and depend on network
configuration, signal strength, and features selected
Table 1. Specifications
General Function Specification
Frequency Range EGSM TX: 880 - 915 MHz
Frequency (MHz) = 890 + (0.2 × n) where: 0 ≤ n ≤ 124
Frequency (MHz) = 890 + (0.2 × (n – 1024)) where: 975 ≤ n ≤
1023
RX: 925 – 960 MHz
Frequency (MHz) = 935 + (0.2 × n) where: 0 ≤ n ≤ 124
Frequency (MHz) = 935 + (0.2 × (n – 1024)) where: 975 ≤ n ≤
1023
Frequency Range DCS TX: 1710 to 1785 MHz
Frequency (MHz) = 1710 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 885
RX: 1805 to 1880 MHz
Frequency (MHz) = 1805 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 885
Frequency Range PCS TX: 1850 to 1910 MHz
Frequency (MHz) = 1850 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 810
RX: 1930 to 1990 MHz
Frequency (MHz) = 1930 + (0.2 × (n – 512)) where: 512 ≤ n ≤ 810
Frequency Range UMTS TX: 1920 to 1980 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 9612 < UARFCN
1
<
9888
UARFCN
1
in increments of 25
RX: 2110 to 2170 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 10562 < UARFCN
1
<
10838
UARFCN
1
in increments of 25
Channel Spacing 200 kHz (GSM, DCS, PCS), 5MHz UMTS
Channels 174 EGSM, 374 DCS, 274 PCS carriers with 8 ch. Per carrier,
11 UMTS
Duplex Spacing 45 MHz GSM, 95 MHz DCS, 80 MHz PCS, 190 MHz UMTS
Modulation GMSK AT BT = 0.3 (GSM, DCS, PCS), QPSK (UMTS)
Transmitter Phase Accuracy 5 degrees RMS, 20 Degrees peak
Frequency Error +
0.1ppm
Input/Output Impedance 50 ohms (nominal)
Nominal Operating Voltage 3.6 Vdc +
10% (battery)
+4.4 Vdc +10% (external connector)
Dimensions (Volume)
(w/Standard battery)
148.5 x 60 x 24.3 (mm),
5.8 x 2.3 x 0.96 (in)
Volume 115 cc, 10.5 in
3
Weight 160 g, (6.75 oz) with battery, without stylus
Display TFT active matrix full color display (262K colors)
240 x 320 pixel LED front lighting
Battery Life (1600mAh)
2
GSM: Up to 225 min. (Talk Time), up to 200 hours (Standby)
WCDMA: Up to 100 min. (Talk Time), up to 185 hours (Standby)
Nominal Temperature Range -20º C to +50º C
