Technical Specifications
A-5
A.4 Antenna Specifications
The antenna suite differs between the AP-5131 and AP-5181 model access points. Ensure your have
selected the correct model antenna before deploying the access point. For more information, see:
• AP-5131 Antenna Specifications
• AP-5181 Antenna Specifications
A.4.1 AP-5131 Antenna Specifications
A.4.1.1 2.4 GHz Antenna Matrix
The following table describes each 2.4 GHz antenna approved for use with the AP-5131.
Radio Data Rates 802.11a radio 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/Sec
802.11g radio 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/Sec
802.11b radio 1, 2, 5.5, 11 Mbps
Wireless Medium Direct Sequence Spread Spectrum (DSSS)
Orthogonal Frequency Division Multiplexing (OFDM)
CAUTION The antenna models described below are rated just for the AP-5131
model access point and its intended indoor deployment. They are not
intended for outdoor use with an AP-5181 model access point.
CAUTION Using an antenna other than the Dual-Band Antenna (Part No.
ML-2452-APA2-01) could render the AP-5131’s Rogue AP Detector
Mode feature inoperable. Contact your Motorola sales associate for
specific information.
Part Number Antenna Type Nominal Net Gain (dBi)
ML-2499-11PNA2-01R Wide Angle Directional 8.5
ML-2499-HPA3-01R Omni-Directional Antenna 3.3
ML-2499-BYGA2-01R Yagi Antenna 13.9
ML-2452-APA2-01 Dual-Band 3.0
!
!
