A.4.1.2 5.2 GHz Antenna Matrix
The following table describes each 5.2 GHz antenna approved for use with the AP-5131.
A.4.1.3 AP-5131 Additional Antenna Components
The following table lists the Motorola part number for various antenna accessories. This table also
includes the loss for each accessory at both 2.4 and 5.2 GHz.
A.4.1.4 AP-5131 Antenna Accessory Connectors, Cable Type and Length
The following table describes each antenna accessory’s connector and cable type, plus the length.
Part Number Antenna Type Nominal Net Gain (dBi)
ML-5299-WPNA1-01R Panel Antenna 13.0
ML-5299-HPA1-01R Wide-Band Omni-Directional
Antenna
5.0
ML-2452-APA2-01 Dual-Band 4.0
Item Part Number Description
Loss (db)
@ 2.4 GHz
Loss (db)
@ 5.2 GHz
72PJ ML-1499-72PJ-01R Cable Extension 2.5
LAK1 ML-1499-LAK1-01R Lightning
Arrestor+
0.75
LAK2 ML-1499-LAK2-01R Lightning Arrestor 0.25
10JK ML-1499-10JK-01R Jumper Kit 0.75 1.6
25JK ML-1499-25JK-01R Jumper Kit 1.9 3.5
50JK ML-1499-50JK-01R Jumper Kit 3.75 6.6
100JK ML-1499-100JK-01R Jumper Kit 7.5 12.8
Item Connector1 Connector2 Length (meters) Cable Type
72PJ RPBNC-F RPBNC-M 1.83 RG-58
