Hardware Installation
2-13
For more information and device specifications for the Power Injector, refer to the Power Injector
Quick Install Guide (Part No. 72-70762-01) available from the Motorola Web site.
2.7 Mounting an AP-5131
The AP-5131 can rest on a flat surface, attach to a wall, mount under a suspended T-Bar or above a
ceiling (plenum or attic). Choose one of the following mounting options based on the physical
environment of the coverage area. Do not mount the AP-5131 in a location that has not been approved
in a site survey.
Refer to the following, depending on how you intend to mount the AP-5131:
• Desk Mounted Installations
• Wall Mounted Installations
• Suspended Ceiling T-Bar Installations
• Above the Ceiling (Plenum) Installations
2.7.1 Desk Mounted Installations
The desk mount option uses rubber feet allowing the unit to sit on most flat surfaces. The four (4)
round rubber feet can be found in the AP-5131 (main) box in a separate plastic bag.
To install the AP-5131 in a desk mount orientation:
1. Turn the AP-5131 upside down.
2. Attach the radio antennae to their correct connectors.
The antenna protection plate cannot be used in a desk mount configuration, as the plate only
allows antennas to be positioned in a downward orientation.
LED AC (Main) Port
Green (Steady) Power Injector is receiving power from an
AC outlet.
Indicates a device is connected to the
Power Injector’s outgoing Data & Power
cable.
Green (Blinking) Output voltage source is out of range. The Power Injector is overloaded or has a
short circuit.
To Next Page
